Chargepipe Audi
-
2.0 TFSI silicone hose for power pipe from intercooler to the throttle valve
The hose is made of 4-layer silicone and can withstand the very high temperatures of a tuned engine without any problems.
Features:
- 4-ply black silicone
The kit includes:
- Silicone hose in black
- 2x hose clamps
Fits both the K03 and the K04 Turbo.
More power, torque and durability!
Click here for the complete boost pipe kit!
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
2.0L TFSI silicone hose from Turbo Outlet to pressure pipe.
Facts:
- 4-layer black silicone tube
- diameter: 60mm
Fits only when converting to K04 loaders (such as the Audi S3).
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
2.0L TSI pressure pipe for Golf 7, Audi A3 & S3
Our pressure pipe for the turbocharger pressure side up to intercooler: Perfectly suited for 2.0L TSI engines like in the Golf 7 GTI, Audi A3 and S3 and many more.
The original pipes can cause unwanted loss of performance especially in tuned engines. They are made of plastic and so narrow that the air flow is swirled. As a result, not enough power arrives.
That\'s why our tubes are made of aluminum and bent so that the maximum airflow goes through. So you also achieve the performance you want to have. It also noticeably improves throttle response. The 2.0L TSI pressure pipe kit provides more power, torque and durability!
The powder coating is very durable and gives the OEM look you want.
Facts:
- 2.5\" (63mm) aluminum tubing
- OEM bracket
- Durable powder coating for OEM look
This pipe needs also our special hose and turbo outlet. It is best to purchase our complete kit!
-
2.0l TSI Turbo Outlet Pipe Kit by BAR-TEK® for the 2.0T engines built in VW Golf MK7 GTI, Audi A3 and S3
The BAR-TEK® pipe is constructed out of mandrel bent 2.5\" aluminum tubing. Our kit also includes a high temperature 4-ply silicone throttle body hose. The throttle pipe is finished in a durable powdercoat finish for an OEM look.
Features:- 2.5\" Aluminum piping
- OEM style bracket
- Durable powdercoat finish
- 4-ply silicone hose
- complete kit
Includes:
- Throttle pipe
- Silicone hose
- (2) hose clamps
- (2) MAP sensor screws
Application Guide:
- Audi A3 8V 2.0L TSI
- Audi S3 8V 2.0L TSI
- VW Golf MK7 GTI 2.0L TSI
- VW Golf MK7 GTI Clubsport
- VW Golf MK7 Performance
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
2.0L TFSI power pipe with silicone hose from the intercooler to the throttle body.
Our power pipe for 2.0L TFSI engines as in the Golf 5, Audi A3, TT and Co.Since the series pipes made of plastic and become very narrow, they become the optimal air flow from the LLK to the throttle valve. The original pipes do not hold up to the political boost pressure of a tuned engine. This can even result in major engine damage if the pipe bursts.
Our power tube requires aluminum and is bent like a spindle. It becomes for the air flow and therefore a top performance and performance of your turbocharger. The response behavior is made clear. This way you can use the full power - without worrying about the pipe bursting.
The hose is made of 4-layer silicone and also belongs to the very high stock of a tuned motor without any problems.
The robust powder coating is part of the power tube and belongs to the OEM look.
Features:
- 6.35 cm (2.5 \") aluminum pipe
- OEM bracket
- Permanent powder coating for an OEM look
- 4-layer black silicone
The kit includes:
- Powder coated power tube
- Black silicone hose
- 2x hose clamps
- 2x screws for card sensor
Also fits the K03 (here the plug for the SUV must be used) as well as the K04 Turbo.
More power, torque and durability!
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
още
2.0 TFSI Pressure pipe kit for conversion to K04 turbocharger
With our 2.0 TFSI pressure pipe kit, you get the perfect connection from the turbo to the intercooler in S3 technology!
The original pipes are made of plastic and are very narrow, which leads to an obstruction of the air flow. With tuned engines with increased power, the high boost pressure can even cause the original pipe to burst. In the worst case, you run the risk of major engine damage.
Our pipes have a larger diameter, are made of aluminium and are bent like a spindle. This ensures the maximum and best air flow. The response behaviour of the turbocharger improves and you can get the maximum power out of it.
Unlike other pipes on the market, our pipes come with an aluminium exhaust adapter and 4-layer silicone hose connectors.
The hoses can easily withstand the high temperatures of a tuned engine. The robust powder coating gives the pipework a high-quality OEM look.
Facts:
- 2.25\" (5.7cm) aluminium tubing
- OEM bracket
- CNC Aluminium outlet adapter
- Durable powder coating
- 4-layer black silicone tubing
- Complete all-round carefree package
The kit includes:
- Turbo pressure pipe
- Silicone hose from turbo to drain pipe
- Silicone hose from drain pipe to intercooler
- CNC Aluminium outlet adapter
- 4x hose clamps
Suitable for:
- Audi TTS MK2 (2008+) 2.0 TFSI
- Audi A3 MK1 (05 - 2013) 2.0 TFSI
- Volkswagen Jetta MK5 (05.5 - 2010) 2.0 TFSI
- Volkswagen Golf/GTI/Rabbit MK5 (06 - 2009) 2.0 TFSI
- Volkswagen R Models MK6 R (2011+) 2.0 TFSI
- Seat Leon Cupra R 1P
Important: The BAR-TEK® 2.0 TFSI pressure pipe kit does not fit the Golf 5 GTI, Jetta, Audi A3 etc. with K03 supercharger!
Only fits when converted to a K04 charger (e.g. Audi S3).
If a upgrade- intercooler is installed, the hose between intercooler and pressure pipe from upgrade- intercooler must also be used.
Vehicles with the original S3 intercooler require a different hose for connection to the S3 intercooler. Please select the version above.
We have successfully tested this kit in our 2.0L Audi A3 TFSI. Nürburgring tested!
Click here for the complete boost pressure pipe kit with TÜV certificate !
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
2.0L TSI pressure pipe for Golf 7, Audi A3 & S3
Our pressure pipe for the turbocharger pressure side up to intercooler: Perfectly suited for 2.0L TSI engines like in the Golf 7 GTI, Audi A3 and S3 and many more.
The original pipes can cause unwanted loss of performance especially in tuned engines. They are made of plastic and so narrow that the air flow is swirled. As a result, not enough power arrives.
That\'s why our tubes are made of aluminum and bent so that the maximum airflow goes through. So you also achieve the performance you want to have. It also noticeably improves throttle response. The 2.0L TSI pressure pipe kit provides more power, torque and durability!
The powder coating is very durable and gives the OEM look you want.
Facts:
- 2.5\" (63mm) aluminum tubing
- OEM bracket
- Durable powder coating for OEM look
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
2.0 TFSI Intercooler pressure pipe kit for K03 and K04 turbocharger
With our 2.0 TFSI pressure pipe kit, you have the perfect connection from the turbo to the intercooler in S3 technology.
The original pipes are made of plastic and are so narrow that the air flow is obstructed. Especially with tuned engines, performance is lost!Our boost pipes, on the other hand, come with an aluminium turbo outlet and four-layer silicone hose connectors. They are bent in such a way that they allow the highest flow rate. This significantly improves the response behaviour of the turbo. You get more power, torque and durability. And of course, driving is much more fun!
Naturally, our hoses are designed to withstand even the highest temperatures with ease. Thanks to the durable powder coating, you also have the high-quality OEM look.
Features:
- 2.25\" (57 mm) aluminium tubing
- 2.5\" (63.5 mm) power tube
- OEM bracket
- CNC Aluminium turbo outlet
- Durable powder coating
- 4-layer black silicone hoses
- Complete all-round carefree package
- Optionally with TÜV certificate (only for vehicles with standard K04 turbocharger)
The kit includes:
- Turbo pressure pipe
- Power pipe, powder-coated
- Silicone hose for the power pipe
- Silicone hose from the turbo to the drain pipe
- Silicone hose from the drain pipe to the intercooler
- CNC Aluminium turbo outlet
- Hose clamps
- Screws for the map sensor
- Optional TÜV certificate
Important: The BAR-TEK 2.0 TFSI pressure pipe kit naturally also fits the TFSI with K03 supercharger such as e. g. in the Golf 5 GTI, Jetta or A3. The certificate is not valid for vehicles with a K03 turbo.
If a upgrade- intercooler is installed, the hose between intercooler and the pressure pipe from upgrade- intercooler must also be used.
Vehicles with the original S3 intercooler require a special hose for connection to the S3 intercooler. You can simply select this as an option!
If you have an original intercooler with \"click lock\", you will need our click adapter to connect the silicone hose to the OEM radiator. You can find this at accesories.
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
Now with TÜV: Boost pipe kit for 2.0L TSI EA888 Evo4
This is our complete pressure pipe kit for 2.0L TSI engines like in the Golf 8 GTI.
With our pressure pipe kit, you ensure the best air flow and therefore significantly better response and more performance.
The usual standard pipes are made of plastic and are very narrow, resulting in air turbulence. Our pressure pipes are made of high-quality aluminum and shaped like a spindle. This allows the air to flow optimally, giving you more torque and power!
Our pipes come with aluminum outlet adapters and 4-layer silicone hose connectors. This means they can withstand very high temperatures and are perfect for ambitious riders. The look is also impressive: The powder coating provides the high-quality OEM look.
Facts:
- 2.5\" (63mm) aluminum tubing
- OEM bracket
- CNC aluminum outlet adapter
- Durable powder coating
- 4-layer black silicone hoses
- Complete all-round carefree package
- Suitable for all Golf 8 GTI models
The kit includes:
- 2x turbo pressure pipes
- Silicone hose from the pressure pipe
- Hose clamps
- TÜV certificate
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
The aluminum charge air pipes replace the OEM plastic pipes, which tend to burst. This defect can in the worst case lead to engine damage due to aspirated fragments.
The charge pipe made of aluminum has an increased diameter compared to the original. This reduces air turbulence and at the same time increases the air flow. This leads to a faster response of the turbocharger and a higher maximum possible power.
The engine software does not have to be retuned in this case. Even at very high boost pressures, there is no longer any risk of bursting. In addition, the kit provides a good basis for retrofitting a water-methanol injection system. A connection for one is already prepared.
The installation is relatively simple since this Charge Pipe Plug\'n\'play is exchanged against the series part. This Charge Pipe Kit replaces the BMW original parts with the part numbers: 11617846245, 11617846246, 11617846248
Manufacturer
Information about the manufacturer
BAR-TEK®
BAR-TEK Motorsport GmbH
Im Rauschen Auel 3, 51491 Overath-Brombach, Germany
-
The optimised boost pipe kit from Forge increases the flow rate and enables higher performance for your 2.0L TSI Evo4 engine. The high-quality aluminium pipes serve as a direct replacement for the OEM plastic pipe.
The OEM pipe can become brittle and even break under increased boost pressure.
The diameter of the pressure pipe is increased to 76 mm from the turbo outlet to the intercooler inlet. -
The optimised boost pipe kit from Forge increases the flow rate and enables higher performance for your 2.0L TSI Evo4 engine. The high-quality aluminium pipes serve as a direct replacement for the OEM plastic pipe.
The OEM pipe can become brittle and even break under increased boost pressure.
The diameter of the pressure pipe is increased to 70 mm and is reduced to the OEM diameter again before the inlet of the Intercooler.
